TRENDnet | SKU: TNTEG-082WS

TRENDnet TEG-082WS 8 Port Gigabit Web Smart Switch, 10/100/1000 Mbps, SFP, rack mountable, fanless

Name: TRENDnet TEG-082WS 8 Port Gigabit Web Smart Switch, 10/100/1000 Mbps, SFP, rack mountable, fanless
Brand: TRENDnet
SKU: TNTEG-082WS
Availability: InStock

MPN:

⚠️ Authorized Dealers Only

Pricing and checkout are disabled unless you're an authorized dealer. Please log in or apply below.

TRENDnet TEG-082WS 8 Port Gigabit Web Smart Switch, 10/100/1000 Mbps, SFP, rack mountable, fanless is backordered and will ship as soon as it is back in stock.

Description

8-Port Gigabit Web Smart Switch (TEG-082WS)

8 x Gigabit ports
2 x shared SFP slots
16 Gbps switching capacity
Built-in power supply
Advanced Web Smart management
Fanless design reduces energy consumption and operating noise
Rackmount brackets included

Overview

	Hardware Design Provides eight gigabit ports, two SFP slots, a 20Gbps switching capacity, a built-in power supply, and rackmount brackets.
	IPv6 Ready This switch supports IPv6 configuration and IPv6 neighbor discovery.
	Traffic Management A broad range of network configurations are supported by: 802.3ad link aggregation, Asymmetric VLAN, 802.1Q VLAN, Voice VLAN, RSTP, MSTP, Loopback Detection, GVRP, 802.1p Class of Service (CoS), port bandwidth management, and QoS queue scheduling.
	Troubleshooting A convenient cable diagnostic test and traffic statistics aid in network troubleshooting.
	Access Control Features such as ACL, SSL, MAC/port filtering, 802.1X, TACACS+, and RADIUS are compatible with layered access controls.
	Monitoring RMON, SNMP, SNMP Trap, and Port Mirroring support administrator monitoring solutions.

Feature

TRENDnet’s fanless 8-Port Gigabit Web Smart Switch, model TEG-082WS, offers 8 x Gigabit ports, 2 x shared SFP slots, a built-in power supply, and a 16 Gbps switching capacity. This IPv6 ready switch offers advanced traffic management, troubleshooting, access control, energy saving GREENnet, and monitoring features at a reduced cost.

Hardware Design

Provides 8 x Gigabit ports, 2 x shared SFP slots, a 16 Gbps switching capacity, a built-in power supply, and rackmount brackets.

Specs

Standards	IEEE 802.1D IEEE 802.1Q IEEE 802.1S IEEE 802.1X IEEE 802.1p IEEE 802.1w IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3z IEEE 802.1ab IEEE 802.3ab IEEE 802.3ad IEEE 802.3az
Device Interface	8 x Gigabit ports (ports 1-8) 2 x Shared SFP slots (shared with ports 7 - 8) LED indicators
Data Transfer Rate	Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex) Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex) Gigabit Ethernet: 2000 Mbps (full duplex)
Performance	Switch fabric: 16 Gbps RAM buffer: 1 MB MAC Address Table: 16K entries Jumbo Frames: 10 KB HOL Blocking Prevention Forwarding rates: 11.9 Mpps (64-byte packet size)
Management	HTTP/HTTPS (SSL v2/3 TLS) Web based GUI SNMP v1, v2c, v3 RMON v1 Static Unicast MAC Address Enable/disable 802.3az Power Saving LLDP Virtual Cable Test IPv6: IPv6 Neighbor Discovery, IPv6 Static IP, DHCPv6, Auto configuration
MIB	MIB II RFC 1213 Bridge MIB RFC 1493 Bridge MIB Extension RFC 2674 SNMPv2 MIB RFC 1907 Ethernet Interface MIB RFC 1643 Ethernet –like MIB RFC 2863 Interface Group MIB RFC2233 MIB Traps Convention RFC 1215 RMON MIB RFC 1757, RFC 2819 802.1p MIB RFC 2674 RADIUS Client Authentication MIB RFC 2618 LLDP-MIB IEEE 802.1ab Ping MIB RFC 2925, RFC 4560
Spanning Tree	IEEE 802.1D STP (Spanning Tree protocol) IEEE 802.1w RSTP (Rapid Spanning Tree protocol) IEEE 802.1s MSTP (Multiple Spanning Tree protocol)
Link Aggregation	Static Link Aggregation 802.3ad Dynamic LACP
Quality of Service (QoS)	802.1p Class of Service (CoS) DSCP (Differentiated Services Code Point) Bandwidth Control per port Queue Scheduling: Strict Priority, Weighted Round Robin (WRR)
VLAN	Multiple management VLAN assignment Asymmetric VLAN 802.1Q Tagged VLAN Dynamic GVRP Up to 256 VLAN groups, ID Range 1-4094 Private VLAN (Protected Ports) Voice VLAN (10 user defined OUIs)
Multicast	IGMP Snooping v1, v2, v3 (per VLAN) Static Multicast Address Up to 256 multicast entries
ACL IPv4 L2-L4 & IPv6	MAC Address VLAN ID Ether Type (IPv4 only) IP Protocol 0-255 TCP/UDP Port 1-65535 802.1p DSCP (IPv4 only) IPv6 Address (IPv6 only)
Compatibility	Optional Software Utility: Windows^® 8.1, 8, 7, Vista, XP, Windows^® 2003/2008 Server
Special Features	Fanless design IPv6 802.3az power saving Rack mountable
Power	Input: 100 - 240 V AC, 50/60 Hz, internal power supply Consumption: 13.8 Watts (Max.)
MTBF	1,054,337 hours
Temperature	Operating: 0 – 45 °C (32 - 113 °F)
Operating Humidity	Max. 90% non-condensing
Dimensions	280 x 180 x 44 mm (11 x 7.1 x 1.7 in.) Rack mountable 1U height
Weight	1.5 kg (3.4 lbs.)
Certifications	CE FCC
Warranty	3 year limited

TRENDnet TEG-082WS 8 Port Gigabit Web Smart Switch, 10/100/1000 Mbps, SFP, rack mountable, fanless
