Ubiquiti U6-MESH-US UniFi 6 Indoor/Outdoor Access Point Mesh
- Wi-Fi 6 (802.11ax)
- Up to 5374 Mb/s Throughput
- 2.4 GHz / 5 GHz (Dual-Band)
- 1 x Gigabit Ethernet PoE Port
- Includes PoE Adapter
- IPX5 Rated
- Wall & Pole Mounting Kits Included
- Supports UniFi Network Application
Quickly expand your business's wireless network coverage with the U6-Mesh-US Wireless Dual-Band Wi-Fi 6 Mesh Outdoor Access Point from Ubiquiti Networks. Designed for outdoor installations, this 802.11ax access point is IPX5 rated for weather resistance and can withstand temperatures between -22° and 140°F. With support for the 160 MHz channel, customers, employees, and clients can transfer up to 4.8 Gb/s over the 5 GHz band and 574 Mb/s through the 2.4 GHz frequency with compatible devices.
This access point is designed to handle over 300 concurrent users. Use the included PoE adapter to power the access point through its Gigabit Ethernet uplink port. Wall and pole mounting kits are included for flexible positioning. The U6-Mesh-US Wireless Dual-Band Wi-Fi 6 Mesh Outdoor Access Point may be managed with the UniFi Network application v6.3.51 and later.
UniFi Network Application Features
- Centrally manage multiple networks from an intuitive interface
- Real-time device insights and deep configuration options
- Upgrade device firmware remotely
- Manage network users and guests
- Personalize the design, architecture, and privacy of guest hotspots
- Set up devices quickly and manage them on the go with a mobile app
| Wi-Fi | Wi-Fi 6 (802.11ax) |
|---|---|
| Inputs/Outputs | Satellite: 1 x RJ45 Gigabit Ethernet (WAN) PoE |
| MU-MIMO Support | 4 x 4 |
| Wireless Security | WPA-PSK, WPA-Enterprise, WPA2-PSK, WPA2-Enterprise, WPA3-PSK, WPA3-Enterprise |
| Bluetooth | Yes |
| Communication Protocol | None |
| Virtual Assistant | None |
| Throughput | 5374 Mb/s Total 5 GHz: 4800 Mb/s 2.4 GHz: 574 Mb/s |
| Antenna Gain | 3 to 5 dBi |
| Operation Modes | Access Point |
| Supported IEEE Standards | 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n, 802.1q, 802.3af |
| Speakers | None |
| Built-In Microphones | None |
| Display | None |
| DC Input Power | 57 VDC |
| Power Consumption | 11.4 W |
| Operating Temperature | 2 to 92°F / -30 to 60°C |
| Operating Humidity | 5 to 95% |
| IP Rating | IPX5 |
| Environmental Protection | Advertised as Water Resistant *Manufacturer Testing: IPX5 |
| Material of Construction | Plastic, Aluminum |
| Dimensions | 1.9 x 6.3 x 1.9" / 48.5 x 159.5 x 48.5 mm |
| Weight | 14.1 oz / 400 g |
