Video Input: 8 channel BNC input +4 IP channel up to 8MP/4K
Resolution: Up to 8MP
Video Output: 1-ch HDMI output, 1-ch VGA output at up to 1920*1080
Support: TVI, AHD, CVI, CVBS, IP cameras with adaptive access
Hard Drive: 2 SATA Bays Up to 6TB each
Audio: 1ch output, 1ch two way input , Over Coax
App: Guard Viewer App
Warranty: 1 Year
Sensor:High quality image with 8MP, 1/2.7"CMOS sensor
Resolution:8MP /4K
Lens: 2.8mm Fixed
Functions: 3D DNR , WDR, 9:16 Corridor Mode
IR Range: Smart IR, up to 30m (98ft) IR distance
Menu: OSD
Audio: Built-in Mic and Speaker
Micro SD: Supports 256GB Micro SD card
Power: Support PoE power supply or DC 12V±25%
Protection: IP67
Warranty: 3 Years
Capacity
4 TB
Cache Memory Installed Size
64 MB
Disk Speed (RPM)
5,400 rpm
Hard Disk Form Factor
3.5 in
Hardware Connectivity
SATA 6.0 Gb/s
Dimensions (L x W x H)
5.79" x 4" x 1.03"
Compatibility
WD Purple™ surveillance storage is built to handle up to 64 cameras per drive and is designed for 24/7, always on, high-definition surveillance security systems with more than eight bays.
