Panamax M5400PM, 11 Outlets Power Management, Black
by Panamax
SKU PNM5400PM
Panamax Max 5400 Power Management w/ Voltage Regulation, 2RU, 11 Outlets
The Panamax M5400-PM delivers high-level protection for your audio/video system. It guards against harmful spikes and maintains outgoing current at a consistent, optimal level, giving you pure, noise-free picture and sound. The 5400-PM can safeguard up to 11 components, and it includes a protected front-panel USB charger for your MP3 player, cell phone or another portable electronic device.
- 11 AC outlets with 5 isolated banks:
- two isolated banks of two switched outlets
- two isolated banks of two always-on outlets
- one isolated bank of two switched high-current outlets with delayed on/off
- one front-panel convenience outlet
- front-panel USB charger
- voltage regulation circuitry ensures that your system receives a consistent, optimal amount of power
- surge and over- and under-voltage protection
- filtration circuitry virtually eliminates line noise
- three sets of coaxial RF connections for cable/satellite/TV antenna
- two sets of RJ-45 Ethernet line inputs and outputs, including one front-panel connection
- RJ-11 phone line input and output
- 12-volt trigger input for delayed outlets
- front-panel digital voltmeter and ammeter
- 2125-joule surge protection
- maximum current rating: 15 amps
| Total AC Outlets | 11 |
|---|---|
| High-Current Outlets | 2 |
| USB Connections | 1 |
| RF-EMI Filtering | Yes |
| Joule Rating | 2125 |
| Powerline Network Compatible | No |
| Connected Equipment Guarantee | $5.000.000 |
| Width (inches) | 17 |
| Height (inches) | 4-1/8 |
| Depth (inches) | 14-3/4 |
| Weight (pounds) | 20 |
