Parasound ZDACBk 192kHz Digital to Analog Converter

This website is for Authorized Dealers only. Pricing and checkout is disabled unless you are authorized. "Login" or Click "Dealer Application" to apply.

Parasound Zadac 192kHz Digital to Analog Converter

The Zdac sounds more natural and less "digital" because of its innovative design and high quality parts. Its unique re-clocking system preserves the original source audio data by eliminating jitter contamination that is picked up along the digital signal chain. This is accomplished through the synergy of two premium parts, an Analog Devices AD1895 asynchronous sample rate converter and an AD1853 DAC IC, the same DAC IC that Holm selected for our Halo CD 1 CD player. To further improve sound quality the signal is up-sampled to 422kHz. This highly effective jitter-reduction system works on all inputs, not just the USB input.

  • Premium Analog Devices AD1853 24-bit/192 kHz Digital to Analog Converter IC
  • All inputs feature jitter reduction and are re-clocked and up-sampled to 422 kHz / 24 bit
  • USB input for playing music from PC or Mac (driver-less for easy setup)
  • Asynchronous sample rate conversion for all inputs including the USB input
  • Works with any format file on your computer up to 96 kHz / 24 bit
  • Works in variable volume mode in Windows® for connecting direct to a power amp (no preamp needed)
  • Optical and Coaxial digital inputs for use with any standard digital connection
  • RCA unbalanced and XLR balanced analog outputs
  • High current headphone output with volume control can drive any headphones from 32 to 600Ω
  • Oversized internal toroid power transformer
  • Will always power back up to the same input in the event of an AC power outage
  • Available in Black (Rack mount option available for Black units)
Supports Incoming Digital Word Lengths 16 bit - 24 bit
Supports Incoming Digital Sampling Frequencies / Opt & Coax 8 kHz, 11.025 kHz, 16 kHz, 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz.
Supports Incoming Digital Sampling Frequencies / USB 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz
Up-sampling Frequency 422 kHz / 24 bit (all inputs)
Sample Rate Converter Analog Devices AD1895
D to A Converter Analog Devices AD1853
Frequency Response 20 Hz to 20 kHz ±0.2 dB
Channel Balance < 0.05 dB, 20 Hz - 20 kHz
Channel Separation > 95 dB, 20 Hz - 20 kHz
Signal to Noise Ratio 110 dB, A-weighted
THD + Noise < 0.015 %
Audio Output Level Unbalanced: 2.1 V RMS (Balanced: 4.2 V RMS)
Output Impedance Line out: 160 ohms, balanced or unbalanced / Headphone out: 10 ohms
AC Power Requirement 10 watts (110-130 VAC 60 Hz or 220-240 VAC 50 Hz) Selector on Bottom
Dimensions Width: 9.5” Depth: 10" Height, with feet: 2" ; without feet:1.75"
Weight Net: 5 lbs / Shipping: 8 lbs
