by KEF
SKU KFCI3160RLTHX
One Pair of White Cover Plates for C600 Ceiling Speaker Holes
KEF’s Ci3160RL-THX is an in-wall speaker certified to THX ULTRA2 standard featuring a 6.5in. Uni-Q driver array with a pair of 6.5in. MF drivers.
You can position the Ci3160RL-THX as a front or rear side channel speakers, or position horizontally as a center channel.
For the ultimate in custom installed Extreme Home Theatre, the formidable new Ci R Series has the jaw-dropping acoustic capabilities of the classic KEF floorstander it’s named after, with all the drama and emotional intensity of full theatre sound quality.
The Ci R Series consists of an in-ceiling speaker that can be combined with one of two in-wall models, and a sensational new powered subwoofer. As you might expect, its towering performance sets a new standard for custom installed speakers.
The Ci3160RL-THX is crafted with a massive aluminium baffle to eliminate vibration and is the perfect platform for the 160mm aluminium cone Uni-Q with tangerine waveguide, and four 160mm woofers. Capable of bi-wire and bi-amplifier connections the Ci3160RL-THX delivers on the performance promise of all KEF R Series speakers.
Nominal Impedance
4Ω
Sensitivity (2.83V/ 1m)
90dB
Frequency response (±6dB)
open-backed
45Hz - 28kHz
Crossover frequency
340Hz, 2.5kHz
Drive units
LF
MF
HF
2 x 160mm (6.5 in.)
160mm (6.5 in.)
25mm (1 in.) Uni-Q
Recommended Amplifier Power
30-180W
Product external dimensions
(H x W x D)
680 x 230 x 105.7 mm
(26.77 x 9.06 x 4.16 in.)
Cut-out dimensions
(H x W)
660 x 209mm
(25.98 x 8.23 in.)
Net Weight
11.7 kg (25.79 lbs)
Mounting depth from surface
99mm (3.9 in.)
One Pair of White Cover Plates for C600 Ceiling Speaker Holes
KEF’s Ci3160RL-THX is an in-wall speaker certified to THX ULTRA2 standard featuring a 6.5in. Uni-Q driver array with a pair of 6.5in. MF drivers.
You can position the Ci3160RL-THX as a front or rear side channel speakers, or position horizontally as a center channel.
For the ultimate in custom installed Extreme Home Theatre, the formidable new Ci R Series has the jaw-dropping acoustic capabilities of the classic KEF floorstander it’s named after, with all the drama and emotional intensity of full theatre sound quality.
The Ci R Series consists of an in-ceiling speaker that can be combined with one of two in-wall models, and a sensational new powered subwoofer. As you might expect, its towering performance sets a new standard for custom installed speakers.
The Ci3160RL-THX is crafted with a massive aluminium baffle to eliminate vibration and is the perfect platform for the 160mm aluminium cone Uni-Q with tangerine waveguide, and four 160mm woofers. Capable of bi-wire and bi-amplifier connections the Ci3160RL-THX delivers on the performance promise of all KEF R Series speakers.
| Nominal Impedance | 4Ω |
|---|---|
| Sensitivity (2.83V/ 1m) | 90dB |
| Frequency response (±6dB) open-backed |
45Hz - 28kHz |
| Crossover frequency | 340Hz, 2.5kHz |
| Drive units LF MF HF |
2 x 160mm (6.5 in.) 160mm (6.5 in.) 25mm (1 in.) Uni-Q |
| Recommended Amplifier Power | 30-180W |
| Product external dimensions (H x W x D) |
680 x 230 x 105.7 mm (26.77 x 9.06 x 4.16 in.) |
| Cut-out dimensions (H x W) |
660 x 209mm (25.98 x 8.23 in.) |
| Net Weight | 11.7 kg (25.79 lbs) |
| Mounting depth from surface | 99mm (3.9 in.) |
