Nest (GA02076-US) Google Video Doorbell Battery Powered (ASH, US)
Monitor your front door with the Doorbell (Battery) from Nest.
This dual-band Wi-Fi doorbell can be powered with the included battery or existing doorbell wiring to capture 960 x 1280 resolution video.
It features a 145° diagonal field of view, up to 10' of night vision, two-way audio with noise cancellation, and a PIR motion and proximity sensor.
The doorbell is IP54 rated for protection from dust and splashing water.
• Battery-powered or hardwired installation with existing doorbell wiring for power
• With a battery-powered installation, you'll receive notifications via your mobile device or your Google Assistant-enabled speakers when someone presses the doorbell
• Hardwired installation enables your existing wired doorbell chime when someone presses the doorbell
• H.264 video codec
• 802.11a/b/g/n Wi-Fi standards
• 3:4 aspect ratio for visibility of guests at your door
• Motion-activated alerts
• Two-way audio via built-in speaker and microphone with noise cancellation
• 6x digital zoom
• Works with Google Home app
• LED status indicators
• TLS/SSL with 128-bit AES encryption, secure boot, automatic security updates, and on-device machine learning
| Resolution and Frame Rate | 960 x 1280 at up to 30 fps |
|---|---|
| Field of View | 145° (Diagonal) |
| Sensor | 1/3" |
| Zoom | Digital: 6x |
| Night Vision | Up to 10' / 3.0 m |
| Motion Sensor | Yes |
| Supported Video Codecs | H.264 |
| Encryption | Yes |
| Display | None |
| Operating System Support | Android, iOS |
| Wi-Fi | Wi-Fi 4 (802.11n); Dual-Band (2.4 & 5 GHz) |
| Wireless Encryption | WPA, WPA2, WEP |
| Bluetooth | 4.0 LE |
| Intercom | Yes |
| Microphone Enhancements | Noise Cancellation |
| Power Type Requirement | Hardwired, Rechargeable Battery |
| Power Requirements | 8 to 24 VAC; 10 VA Transformer |
| Internal Battery Capacity | 6 mAh |
| Battery Chemistry | Lithium-Ion |
| LED Indicators | Yes |
| IP Rating | IP54 |
| Dimensions | 6.3 x 1.8 x 0.9" / 160 x 46 x 24.1 mm |
| Weight | 7.3 oz / 206 g |
