Panamax  |  SKU: PNSM3PRO

Panamax SM3-PRO Compact BlueBOLT enabled System Manager with 3 Outlets, Power Protection, and 2-Port Network Switch.

This website is for Authorized Dealers only. Pricing and checkout is disabled unless you are authorized. "Login" or Click "Dealer Application" to apply.

Panamax SM3-PRO Compact BlueBOLT enabled System Manager with 3 Outlets, Power Protection, and 2-Port Network Switch. is backordered and will ship as soon as it is back in stock.

Loading location-specific inventory...

Description

SM3-PRO 15A BlueBOLT Compact Power Conditioner

  • 2-port network switch
  • 3 outlets (2 banks) with front-panel bank-override button and indicator lights
  • Two accessory ports for external sensors and triggers
  • AVM and Protect-or-Disconnect protection
  • Included mounting kit
Feature

The SM3-PRO 15A BlueBOLT Compact Power Conditioner from Furman is designed to protect your connected equipment from power surges and dangerous voltage conditions. It is compatible with entertainment systems, digital signage, network equipment hubs, and similar setups.

The conditioner filters your AC power for maximum electronic performance and reduces equipment issues with remote hard reboots. The SM3-PRO also provides remote power, energy, network management from any web-enabled device, and visibility on energy usage with cloud-based monitoring and tracking.

The conditioner will automatically reboot your network equipment when connectivity is lost and reduce excess energy consumption with scheduled on/off commands.

Specs
Voltage Protection Rating 330 V L-N, 400 V L-G, 400 V N-G
Under-Voltage Shutoff 95 VAC ± 2 VAC
Over-Voltage Shutoff 134 VAC ± 2 VAC
Discharge Current Nominal: 3000 A
Maximum Current Rating 15 A
Line Voltage 120 VAC, 60 Hz
Initial Clamping Level 200 V
Energy Dissipation 1,800 Joules (8/20 µs)
Networking BlueBOLT enabled
2-Port ethernet switch
2 x RJ-45
10/100 Base-T
Filtration -15.9 dB @ 10 kHz
EMI / RFI Noise Filtration: -43.5 dB @ 100 kHz
-49.3 dB @ 1 MHz
Dimensions 7.0 x 10.0 x 1.6" / 17.8 x 25.4 x 4.1 cm (with mounting bracket)
Weight 4.8 lb / 2.2 kg
