Russound MBX-PRE Wi-Fi Streaming Media Player

SKU RSMBX-PRE
This website is for Authorized Dealers only. Pricing and checkout is disabled unless you are authorized. "Login" or Click "Dealer Application" to apply.

Russound MBX-PRE

The MBX-PRE Streaming Audio Player is designed to offer a simple-to-install and simple-to-configure streaming media solution to add high quality streaming audio content to any audio system. The MBX-PRE can be used as a single stereo audio streaming source for a single room, or supply a single audio stream to a larger whole-house system through its easy-to-use analog line-level/digital (coax/optical) outputs.

  • Independent streaming audio player
  • Built-in AirPlay streaming with full metadata to iOS/Android apps or XTSPlus touchscreens
  • Built-in Chromecast for Audio support with full metadata to iOS/Android apps or XTSPlus touchscreens
  • Bluetooth Audio
  • Hi-Res audio streaming support up to 24-bit/192 kHz
  • USB for Flash or external USB Hard drive-based music collections
  • Digital (PCM) and Analog Stereo Inputs
  • Digital or analog output
  • Can be integrated (as a source) with a Russound MCA-66 or MCA-88 controller or standalone (as a zone) when used with any brand of amplifier or receiver
  • Controllable with the MyRussound App and fully compatible with the Russound XTSPlus in-wall touchscreen
  • Bass, Treble, and Loudness settings available through the MyRussound App
  • Supports local favorites
  • Onboard browser-based configuration, accessible from a smartphone or tablet
  • Mix and match with other MBX-Series® components for versatile system designs
Frequency Response 20Hz to 20KHz
Audio Outputs Analog Analog – Stereo Audio RCA, Digital Optical
Line Audio Output 2V rms
Audio Inputs  3.5mm Analog Stereo Audio, Digital Optical, USB2.0 Media Playback
Communication Ports Ethernet RJ45 10/100 BaseT
Wi-Fi  802.11ac, dual band
Bluetooth Audio Support  Yes
Trigger Output 12vDC @100mA
Music File Formats MP3 (CBR, VBR), WAV (8, 16-bit), OGG Vorbis, FLAC (8, 16-bit), AAC, AAC+ (supports up to 24-bit/192kHz)
Power Requirements 12VDC, 200 watts
Product Dimensions 8.25”W x 7”D x 1.75”H (21cm W x 17.8cm D x 4.5cm H)
Product Weight 1.00 lb (0.58 kg)
