TRENDnet TEG-S80g 8-port Gigabit GREENnet Switch (Metal)

SKU TNTEG-S80g
This website is for Authorized Dealers only. Pricing and checkout is disabled unless you are authorized. "Login" or Click "Dealer Application" to apply.

8-Port Gigabit GREENnet Switch / TEG-S80g (Version v4.1R)

  • Plug and play installation
  • 8 x Gigabit ports
  • 16Gbps switching capacity
  • Up to 70% energy savings with GREENnet technology*
  • Wall mountable metal housing
  • Lifetime Warranty*

The 8-Port Gigabit GREENnet Switch from TRENDnet is a Gigabit Ethernet switch with impressive power-saving features: it can consume up to 70% less power than comparable switches.

The switch features 8 Gigabit Ethernet ports, all of which support Auto-MDIX negotiation. Compatible with all standard Ethernet protocols, the switch can be used to create networks to which computers of any operating system can connect.

  • 8 10/100/1000Mbps Gigabit Ethernet ports, each featuring Auto-MDIX negotiation
  • GREENnet technology reduces power consumption when Ethernet ports are not in use, a connected device is turned off or in power-saving mode, and can adjust signal output based on Ethernet cable length
  • Utilizes the store-and-forward switching method with non-blocking wire-speed performance
  • IEEE 802.3x Full Duplex Flow Control supports full-duplex operation
  • Back pressure Flow Control supports half-duplex operation
  • Features a 4K MAC address table and 128KB of buffer memory
  • Operates and maximizes packet filtering and forwarding rate
  • Supports Jumbo Frame packets, up to 9KB in size
  • Housed in a sturdy metal enclosure
  • Front panel LEDs give indication of network status and activity

Certifications

  • CE
  • FCC
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3az
Device Interface
  • 8 x Gigabit ports
  • LED indicators
Data Transfer Rate
  • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
  • Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
  • Gigabit: 2000Mbps (full duplex)
Performance
  • Data RAM buffer: 192KB
  • Switch fabric: 16Gbps
  • MAC address table: 4K
  • Forwarding rate: 11.9Mpps (64-byte packet size)
  • Jumbo frame: 9KB
Special Features
  • GREENnet energy saving technology
  • Metal enclosure
  • Wall Mountable
Power
  • Input: 100 – 240V AC, 50/60Hz, 0.15A
  • Output: 5V DC, 1A external power adapter
  • Max. consumption: 4W
Fan/Acoustics
  • Fanless design
MTBF
  • 2,082,116 Hours
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 150 x 97 x 28mm (5.9 x 3.8 x 1.1 in.)
Weight
  • 365g (12.9 oz.)
