TRENDnet TEW-740APBO2K10 dBi Wireless N300 Outdoor PoE Pre-Configured Point-to-Point Bridge Kit

SKU TNTEW-740APBO2K
This website is for Authorized Dealers only. Pricing and checkout is disabled unless you are authorized. "Login" or Click "Dealer Application" to apply.

10 dBi Wireless N300 Outdoor PoE Preconfigured Point-to-Point Bridge Kit / TEW-740APBO2K (Version v3.0R)

  • Wireless N300 point-to-point networking (2.4 GHz)
  • Includes two preconfigured wireless N access points
  • IP56 outdoor weather rated housing
  • Built-in 10 dBi directional antenna
  • Supports Access Point, WDS Bridge, WDS Access Point, WDS Station, and Client Bridge modes
  • Proprietary PoE power adapters included
  • 1 x 10/100Mbps PoE-in port, and 1 x 10/100Mbps port

TRENDnet's 10 dBi Wireless N300 Outdoor PoE Preconfigured Point-to-Point Bridge Kit, model TEW-740APBO2K, is the easiest way for you to provide long-distance, point-to-point wireless connectivity. The long-range outdoor access point kit is ideal for use with building-to-building communications, utility poles, surveillance solutions, and more.

Reduce installation time and infrastructure costs. This preconfigured directional point-to-point bridge kit is ready to install out of the box, with no additional WiFi configurations required*. Conveniently link two locations together with Wireless N300 speeds and performance, especially when you are unable to run network cables.

The durable access point housing is IP56 weather rated housing, and designed and tested for harsh, outdoor environments. This long-range outdoor access point bridge kit features built-in, high-performance 10 dBi antennas, and conveniently includes both wall and pole mounting hardware for installation flexibility.

*For future troubleshooting, we recommend assigning the APs valid IP addresses within your existing network.

  • Supports Access Point (AP), Wireless Distribution System (WDS), Repeater, and Wireless Client modes
  • Compliant with 802.11n/g/b technology (2.4 GHz) with data rates up to 300 Mbps
  • Durable enclosure with an IP67 outdoor weather rating
  • Built in 10 dBi directional antenna
  • Comes with a proprietary PoE injector, so that it can connect a regular non-PoE switch
  • Real time logs and statistics help troubleshooting
  • Support for wireless encryption of up to WPA2
  • Create up to eight additional SSIDs
  • Compatible with legacy wireless devices
  • Pole and wall mounting hardware included
  • DDNS support for dyn.com, no-ip.com
  • Schedule radio on/off time policy
Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.1d
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1X
  • IEEE 802.11d
  • IEEE 802.11e
  • IEEE 802.11f
  • IEEE 802.11h
  • IEEE 802.11i
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11k
  • IEEE 802.11n (2.4GHz up to 300Mbps)
  • IEEE 802.11r
Hardware Interface
  • 1 x 10/100Mbps LAN1 port (proprietary PoE max. cable length 60m (197 ft.))
  • 1 x 10/100Mbps LAN2 port
  • LED indicators
  • Reset button
  • Grounding Point
Special Features
  • IP56 weather rated
  • 802.1Q VLAN assignment per SSID
  • Schedule radio on/off time policy
  • 802.11r / 802.11k fast roaming
  • Preconfigured point-to-point bridge kit
Access Control
  • Wireless encryption: WPA/WPA2-PSK, WPA/WPA2-Enterprise, 802.1X
  • Firewall (CPE Mode): NAT, Virtual Server, DMZ Host, PPTP/L2TP/IPsec VPN Passthrough
  • Access Controls: MAC, IP Filter, Layer 2 Client Isolation, Per-SSID client limiting
  • 802.1Q VLAN
  • OAuthentication 2.0 / Walled Garden for guest authentication
  • Customizable captive portal for guest authentication
QoS
  • WMM
Operation Modes
  • Access Point (AP)
  • Access Point (AP) + WDS
  • Wireless Distribution System (WDS)
  • WISP (CPE) + AP
  • Client Bridge + AP
  • Router
  • Control AP (CAP)
SSID
  • Up to 7 SSIDs
Internet Connection Types (WISP (CPE) + AP & Router modes)
  • Dynamic IP (DHCP)
  • Static IP (Fixed)
  • PPPoE (Dynamic IP/Static IP)
  • PPTP (Dynamic IP/Static IP)
Management/Monitoring
  • Local/remote web-based management (HTTP, HTTPS)
  • Local/remote CLI based management (Telnet, SSH)
  • SNMP v2c/v3
  • SNMP Trap
  • Upgrade firmware
  • Backup/restore configuration
  • Event logging
  • Authentication log
  • Reboot
  • Restore to factory defaults
  • Ping test
  • Traceroute
  • LED Control
Frequency
  • FCC: 2.412 - 2.462GHz
  • ETSI: 2.412 – 2.472GHz
  • IC: 2.412 - 2.462GHz
Wireless Channels
  • FCC: 1-11
  • ETSI: 1-13
Modulation
  • 802.11b: DBPK, DQPSK, CCK with DSSS
  • 802.11g/n: BPSK, QPSK, 16-QAM, 64-QAM with OFDM
Media Access Protocol
  • CSMA/CA with ACK
Antenna Gain
  • 10 dBi internal sector antenna
Wireless Output Power
  • 802.11b: FCC: 26 dBm (max.) / CE: 10.4 dBm (max.) / IC: 26 dBm (max.) @ 11Mbps
  • 802.11g: FCC: 25 dBm (max.), CE: 10.5 dBm (max.) / IC: 25 dBm (max.) @ 54Mbps
  • 802.11n: FCC: 28 dBm (max.), CE: 10.6 dBm (max.) / IC: 28 dBm (max.) @ 150Mbps
  • 802.11n: FCC: 27 dBm (max.), CE: 10.6 dBm (max.) / IC: 27 dBm (max.) @ 300Mbps
Receiving Sensitivity
  • 802.11b: -88 dBm (typical) @ 11Mbps
  • 802.11g: -74 dBm (typical) @ 54Mbps
  • 802.11n: -71 dBm (typical) @ 150Mbps
  • 802.11n: -69 dBm (typical) @ 300Mbps
Power
  • Input: 100 – 220V AC, 50/60Hz, 0.5A
  • Output: 12V DC, 1A proprietary/passive PoE injector
  • Max. Consumption: 6.6W
Operating Temperature
  • -22° – 60° C (-7.6° – 140° F)
Operating Humidity
  • Max. 99% non-condensing
Certifications
  • FCC
  • CE
  • IC
Dimensions
  • 195 x 118 x 61mm (7.6 x 4.6 x 2.4 in.) per access point
Weight
  • 304g (10.7 oz.) per access point
