AC1900 High Power Dual Band Wireless USB Adapter TEW-809UB (Version v1.0R)
- Easy setup
- AC1900: 1300 Mbps Wireless AC or 600 Mbps Wireless N bands*
- High power radio and high gain detachable antennas for increased coverage
- Supports Windows® and Mac® operating systems
- NDAA / TAA compliant (U.S. and Canada only)
Features
Standards |
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11g
- IEEE 802.11n (up to 600 Mbps)
- IEEE 802.11ac (up to 1300 Mbps)
|
Hardware Interface |
- USB 3.0 Micro-B port
- LED indicator
- WPS Button
- 4 x RP-SMA female antenna connectors
- 4 x High gain detachable dual band antennas
|
Encryption |
- Wireless encryption: WEP, WPA / WPA2-PSK
|
Compatibility |
- Windows® 10, 8.1, 8, 7, Vista, XP
- Mac OS® 10.6-10.13
|
Special Features |
- 4 high gain dual band detachable antennas and integrated high powered amplifiers for long range connectivity
- High-speed 802.11ac connectivity
- Explicit Beamforming
|
Quality of Service |
|
Frequency |
- 2.4 GHz: (FCC) 2.412 – 2.462 GHz, (ETSI) 2.412 – 2.472 GHz
- 5 GHz: (FCC) 5.150 – 5.250 GHz / 5.745 - 5.825 GHz, (ETSI) 5.150 – 5.250 GHz / 5.500 – 5.700 GHz
|
Modulation |
- 802.11b: CCK, DQPSK, DBPSK
- 802.11a/g: OFDM with BPSK, QPSK and 16/64-QAM
- 802.11n: BPSK, QPSK, 16-QAM, 64-QAM with OFDM
- 802.11ac: OFDM with BPSK, QPSK and 16/64/256-QAM
|
Antenna Gain |
- 2.4 GHz / 5 GHz: 4 x 5 dBi (max.) dual band external / detachable
|
Wireless Output Power |
- FCC: 802.11a: 21 dBm (max.) / ETSI: 18.5 dBm (max.) @ 54 Mbps
- FCC: 802.11b: 23 dBm (max.) / ETSI: 17.5 dBm (max.) @ 11 Mbps
- FCC: 802.11g: 20 dBm (max.) / ETSI: 17 dBm (max.) @ 54 Mbps
- FCC: 802.11n (2.4GHz): 23 dBm (max.) / ETSI: 17.5 dBm (max.) @ 600 Mbps
- FCC: 802.11n (5GHz): 19.5 dBm (max.) / ETSI: 18 dBm (max.) @ 600 Mbps
- FCC: 802.11ac: 20.5 dBm (max.) / ETSI: 17.5 dBm (max.) @ 1300 Mbps
|
Receiving Sensitivity |
- 802.11a: -72 dBm (typical) @ 54 Mbps
- 802.11b: -84 dBm (typical) @ 11 Mbps
- 802.11g: -70 dBm (typical) @ 54 Mbps
- 802.11n (2.4GHz): -90 dBm (typical) @ 600 Mbps
- 802.11n (5GHz): -88 dBm (typical) @ 600 Mbps
- 802.11ac: -84 dBm (typical) @ 1300 Mbps
|
Overview
TRENDnet's AC1900 High Power Dual Band Wireless USB Adapter, model TEW-809UB, upgrades a computer to Wireless AC1900. Quickly connect to a high performance Wireless AC network at 1300 Mbps or to a Wireless N network at 600 Mbps. A high power radio with detachable high gain antennas increase wireless coverage.
• WiFi Performance: Upgrade your computer to 1300 Mbps WiFi AC or 600 Mbps WiFi N to surf, game, and stream 4K HD video.
• Beamforming: Beamforming increases real-time performance by directing stronger wireless signals to each device's specific location.
• Increased Coverage: A high power radio with detachable antennas increase WiFi coverage.
• Easy Setup: Get up and running in minutes with the intuitive guided setup
• AC1900 Dual Band: Connect to an extreme performance 1300 Mbps Wireless AC or 600 Mbps Wireless N network*
• Wireless Coverage: Extended wireless coverage with high power radio and detachable high gain antennas
• LED Indicator: LED indicator conveys device status
• Operating Systems: Compatible with Windows® and Mac® operating systems
