WyreStorm EX-70-G2 HDMI Extender 4K@60Hz 4:2:0 (4K: 35m/115ft / 1080p: 70m/230ft) M UHD HDBaseT, HDCP 2.2 & 2-way PoH, CEC and IR Bidiretional.

SKU WSEX70G2
This website is for Authorized Dealers only. Pricing and checkout is disabled unless you are authorized. "Login" or Click "Dealer Application" to apply.

4K UHD HDBaseT™ Extender Set with HDCP 2.2 & 2-way PoH and CEC Passthrough (4K: 35m/115ft | 1080p: 70m/230ft)

EX-70-G2

With unbeatable value and reliability, the EX-70-G2 extender features HDBaseT Class B technology, extending 4K UHD video, audio, and control up to 35m/115ft.

UHD & HD BEST OF BOTH WORLDS

We might live in a 4K world, but not every application needs it. Compatible with the latest 4K/60 and 1080p sources alike, the EX-70-G2 delivers whatever content you have, wherever its needed.

2-WAY POH FOR FLEXIBLE INSTALL

No two installs are the same, which is why the EX-70-G2 and all H2 Series extenders can be powered from either TX or RX side for the most convenient and flexible installation imaginable.

SMALL BUT POWERFUL

Weighing in for the featherweight title at just 15mm thick, the EX-70-G2 can be installed just about anywhere, but still packs the punch to deliver video, audio, control and power like a champ.

BIDIRECTIONAL CONTROL WHATEVER THE PROTOCOL

Need to send control signals both up and downstream? The EX-70-G2 has you covered with IR, RS-232 and even CEC signals able to be passed-through, end-to-end bidirectionally for simultaneous source & display control.

  • 4K HDMI extender set capable of transmitting AV content over medium distances using a single category cable
  • HDBaseT Class B transmission supporting 1080p up to 70m/230ft
  • 4K UHD transmissions up to 4096x2160p 60Hz 4:2:0 8bit also supported up to 35m/115ft
  • 2ch PCM and multichannel audio supported up to DTS:X and Dolby Atmos™
  • 2-Way PoH allowing TX or RX to be remotely powered from either end for flexible installation options
  • Bidirectional IR pass-through
  • Bidirectional RS-232 pass-through
  • Supports CEC communication between devices*
  • Automatic EDID Management (copy from RX-TX)
  • Low profile 15mm chassis allows quicker, easier installation behind flush-mounted screens
  • Threaded bushings allow use of both standard and locking DC power plugs
  • Visual LED indication for power supply to units, signal status to show established display connection, HDCP presence and HDBaseT link between devices
  • Cable termination follows IEEE-568B standards
  • Energy efficient universal power supply included
  • 1x EX-40-G3 Transmitter
  • 1x EX-40-G3 Receiver
  • 1x 5V DC 1A Power Supply (US/UK/EU/AU)
  • 1x USB-A to Micro-B RX Power Cable
  • 1x IR Emitter
  • 1x IR Receiver4x Mounting Brackets (2x for TX | 2x for RX)
  • 1x Quickstart Guide
  Transmitter / Receiver
Inputs

1x HDMI 19-pin type A

1x HDBaseT™ 8-pin RJ-45 female

Outputs

1x HDBaseT™ 8-pin RJ-45 female

1x HDMI 19-pin type A

Output Video Encoding HDBaseT™ Class B
Encoding Data Rate 9.2Gbps
End to End Latency Formats 10μs (micro seconds)
Audio Formats 2ch PCM | Up to DTS-X and Dolby Atmos
Video Resolutions (Max) Video Resolutions
1920x1080p @60Hz 12bit
1920x1080p @60Hz 16bit
3840x2160p @30Hz 8bit 4:4:4
3840x2160p @60Hz 8bit 4:2:0
4096x2160p @60Hz 8bit 4:2:0
Supported Standards DCI | RGB
Maximum Pixel Clock HDMI: 300MHz | HDBaseT: 297MHz
HDMI HDMI 2.0 | HDCP (v1 chassis 1.4 | v2 chassis 2.2) | EDID Pass-through | CEC Pass-through | DVI/D supported with adapter (not included)
HDBaseT™ HDMI 2.0 | HDCP (v1 chassis 1.4 | v2 chassis 2.2) | EDID Pass-through | 2-way PoH | Bidirectional IR
IR 1x IR TX: 3.5mm (1/8in) TS Mono | 1x IR RX: 3.5mm (1/8in) TRS Stereo
RS-232 1x RS-232: 3-pin Phoenix (v2 chassis only)
Power Supply 18V DC 1A
Max Power Consumption Transmitter: 7W | Receiver: 17W
PoH IEEE 802.3af 15.4W Max | 2-way
Operating Temperature 32°F ~ 113°F (0°C ~ 45°C)
10% ~ 90%, non-condensing
StorageTemperature -4°F to ~ 158°F (-20°C ~ +70°C)
10% ~ 90%, non-condensing
Maximum BTU Transmitter: 24 BTU/hr | Receiver: 58 BTU/hr
  v1 V2 Chassis
Rack Units | Wall Box <1U
Height With | Without Feet 15mm/0.6in
Width With | Without Brackets 109mm/4.3in
Depth With | Without Handles 64.2mm/2.53in
Weight 0.36kg/0.79lbs
Safety and Emission CE | FCC | RoHS
